ECNY-HC-CT
ECNY-HC-CT
$0.00
• Exit-EM combo with extruded aluminum construction
• 6” EXIT letters with ¾” stroke
• Designed for wall mount only
• Remote capable: choice of 30W or 50W unit capacity
• Extruded aluminum construction
• Field-selectable chevron directional indicator offers a choice of direction on-site
• 6” EXIT letters with ¾” stroke and CT symbol of access
• Utilizes (2) high-efficiency 1W LED emergency heads
• Lead acid battery is standard, and provides a minimum of 90 minutes of illumination in emergency mode
• Meets or exceeds UL 924, NFPA 101, NEC and OSHA illumination standards
• 5-year warranty on housings and electronics
Unit Wattage:
Letter Color:
Housing Color:
Number of Heads:
Quantity:
FEATURES
- Extruded aluminum combination unit with the CT symbol of access
- Single face, for wall mount only
- Remote capable: choice of 30W or 50W unit capacity
CONSTRUCTION
- Extruded aluminum construction
- Field selectable chevron directional indicator offers a choice of direction on site
- 6” EXIT letters with ¾” stroke and CT symbol of access
LAMP
- Utilizes two high efficiency 1W LED emergency heads in emergency mode
- EXIT letters illuminated by long-lasting high-output AlInGaP LEDs with a rated life of 10+ years
Electronics
- Dual-voltage input capability: 120/277V
- Low-voltage disconnect
- AC indicator light with test switch
- Brownout protection
Battery
- Lead-acid battery is standard and provides a minimum of 90 minutes of illumination in emergency mode
- Operating temperature range: 0° C to 40° C
Compliance
- Meets or exceeds UL 924, NFPA 101, NEC and OSHA illumination standards
Warranty
- 5 year warranty on housing and electronics. Battery is prorated
